SKY GLIDER
Gliding over the mountains like a bird and landing safely again – who hasn’t dreamed of it?
Pilots have been thrilled with the flight simulator “Sky Glider” all over the mountains. Whether the flight is through a section of the forest or starts at a snow covered peak, the Sky Glider leaves lasting impressions on families, the young and the young at heart!
SKY GLIDER
QUICKFACTS
- Speed downhill up To 85 km/h
- Speed uphill up to 55 km/h
- Flight Length of 450 - 900 m
- Altitude from 10 - 300 hm
- Capacity is from 60 to 80 pph
- Up to 4 Passengers per Flight
Technical Specifications
| Max. Speed Downhill | up to 85 km/h | Haul-Rope | Ø13mm, zinc-coated, as used in ropeways |
| Max. Speed Uphill | up to 55 km/h | Track-Rope | Ø 28mm, zinc-coated, as used in ropeways |
| Flight-Length | 450 - 900 m | Steel Construction | zinc-coated, up to 15m Pillars |
| Altitude | 10 - 300 m | Insert of the Rope Discs | Made out of Robalon © or Becorit © |
| Capacity | 60-80 pph | LAN Connection | Operator Cabin is connected to the Control Unit in the Drive Station, No Connection between Top- and Bottom Station needed |
| Persons per Ride | Max. 4 Persons per Ride | Operator Cabin | Operator Cabin is connected to the Control Unit in the Drive Station |
| Operation | Day & Night, Sunshine or Rain, Operation until -15° | Control Unit | Control Unit uses Safety Inputs of Pilz ©. Specially developed Software and Internet Remote Support help Operating |
| Safety Certificate | TÜV approved according EN13814, designed on International Standards | Drive-Unite | Drive-Unit 150KW inverter Controlled. (Including a wear-resistant brake.) |
| Merchandising | Sell action photos via a photo-booth | Boarding & Exit Area | The Boarding & Exit Area are laid-out on Rubber Mats, which rest on Zinc Coated Grids. |
| Lightning Concept | Let us develop a special lightning concept | Maintenance | Low Maintenance Costs |
| Roof Over & Optical Highlight | Build a Roof-Over for Protection as well as a Optical Highlight | Minimum Height for Passengers | 130 cm |
| Rope Tensions and Safety Disc | Rope Tensions and Safety Disc Brake using Hydraulic. | ||
| Harness / Sizes | 4 sizes (from130cm to 210 cm) |
